IVECO TRUCKS

Iveco Trucks is a leading manufacturer of commercial vehicles, including trucks, buses, and vans. The company is headquartered in Turin, Italy, and has manufacturing facilities in various locations around the world, including, Asia, Africa and South America. Ive Trucks is known for its innovative designs, advanced, and commitment to sustainability.

ivecotrucks
IvecoStralisL1
IvecoStralisHiWay3
IvecoStralisHiWay6
IvecoStralisHiWay2
IvecoEurocargE6
trdrgermany
IvecoEurocargE61
iveco
FB_IMG_1526483154570
ivecotrucks12
ivecotrucks14

Grow Your Vision

As a major player in the global transport world, Iveco is an international leader in the development, manufacture, marketing and servicing of a vast range of light, medium and heavy commercial vehicles. It also manufactures passenger transport vehicles and special vehicles for defence, civil protection and specific missions like fire-fighting. The vehicles adopt the latest engineering technologies, applied to a comprehensive range of engines running on diesel and alternative fuels. These include natural gas (CNG and LNG), bio-fuels, hybrid technologies and electric engines.

Iveco, an acronym for Industrial Vehicles Corporation, is an Italian industrial vehicle manufacturing company based in Turin, Italy, and entirely controlled by CNH Industrial Group. It designs and builds light, medium and heavy commercial vehicles, quarry/construction site vehicles, city and intercity buses and special vehicles for applications such as firefighting, off-road missions, the military and civil defence.



The name Iveco first appeared in 1975 after a merger of Italian, French and German brands.

Its production plants are in Europe, Brazil, Russia, Australia, Africa, Argentina and China, and it has approximately 5,000 points of sales and service in over 160 countries. The worldwide output of the company amounts to around 150,000 commercial vehicles with a turnover of about €10,000,000,000

Iveco was incorporated on 1 January 1975, with the merger of five different brands: Fiat Veicoli Industriali (with headquarters in Turin, Italy), OM (Brescia, Italy), Lancia Veicoli Speciali (Italy), nic (France) and Magirus-Deutz (Germany).

Following the merger, the newly founded Iveco began rationalizing its product range, manufacturing plants and sales network, while keeping the original brands. From 1975 to 1979, the Iveco range included 200 basic models and 600 versions spanning from 2.7 tons of GVW for a light vehicle to over 40 tons for heavy vehicles, as well as buses and engines. In 1977 the light to medium-weight Iveco Zeta range was introduced, replacing the twenty-year-old OM Lupetto. Integrating the Fiat-OM range with the Unic and Magirus lineups was completed by 1980.Iveco moved in to work on increasing productivity and engine development.

In 1978 Iveco launched the first product in the range of light vehicles branded Iveco, the Daily.

In 1980 Iveco built the first turbo diesel engine for heavy industrial vehicles.In this decade the corporate strategy was heavily oriented towards brand promotion and led to the sponsorship of sports events, such as the 1980 Olympic Games in Moscow, the Davis Cup in 1982, the Jacques Cousteau expeditions in the Amazon basin in 1983 and the Raid Pigafetta, during which the Iveco-Fiat 75 PC 4x4 was first to make a full circle of the globe.Two new divisions were also formed: bus diesel engines and firefighting vehicles.

In 1984 Iveco launched the TurboStar, a heavy on-road vehicle that became a best-seller in Italy and an important player in the European market, selling a total of 50,000 in seven years.

In 1985 Iveco made the first light diesel engine with direct injection.

From 1986, Iveco S.p.A. held a 52% stake in Iveco Ford Truck Ltd, a joint venture (and effectively a merger) with Ford of Europe's truck division. Ford plants took over production and sales of the major vehicles in the Iveco range and continued production of the Ford Cargo.

In the mid-1980s, Astra, which produces dumpers and construction site/quarry vehicles in Piacenza, became part of Iveco Group.

In 1989 the first diesel engine with EGR to reduce polluting emissions compatible with commercial vehicles was produced and the new Daily launched that same year was fitted with it.

In 1990, the group purchased 60% control of the Spanish industrial company ENASA, which owned the industrial vehicle builder Pegaso.

In the 1990s, the EuroCargo, EuroTech, EuroTrakker and EuroStar vehicles represented a total facelift for the range.The EuroCargo and the EuroTech were named "Truck of the Year" in 1992 and 1993 respectively and, for the first time, this recognition was awarded to the same manufacturer for two years in a row.

In 1991, the English company Seddon Atkinson was purchased and brought its long heritage of special vehicles for the construction and refuse collection industries.

That same year, the first TurboDaily assembly line was inaugurated at the Nanjing Motor Corporation in China.

In 1992, Iveco took over the primary constructor of industrial vehicles in Australia to form Ital, originally called International Trucks Australia. In 2000 it was renamed Iveco Trucks Australia Limited.

In 1996 firefighting activities in Germany were structured under the company Iveco Magirus Brandschutztechnik GmbH. The following year, these activities were boosted by the arrival of an Austrian company, Löhr, which then became Löhr Magirus.

In 1998 Cursor 8 was launched, followed the next year by Cursor 10, the first diesel engine with a variable geometry turbine and the first common rail diesel engine for heavy industrial vehicles. The 125th anniversary of the presentation of the first Magirus ladder was celebrated together with the delivery of the five-thousandth Magirus aerial ladder produced since the Second World War.

In 2003 Iveco entirely bought out Irisbus, originally part of a joint venture with Renault.

In 2004 Iveco Motors brand was born, which became an umbrella for the production of engines, and the following year it was incorporated into the newly founded Fiat Powertrain Technologies. At the end of 2004, the agreement was reached between Iveco and the Chinese company Saic (Shanghai Automotive Industry Corporation).

In 2006 Iveco sponsored the Winter Olympic Games in Turin with a fleet of 1,200 Iveco Irisbus buses. The year after, Iveco became sponsor of the All Blacks, New Zealand's rugby team.

In 2009 Iveco became the Trucks and Commercial Vehicle Supplier for the Moto GP, together with the historical sponsorship to the Ferrari Racing Team, for which it supplies the vehicles that transport the single-seaters at all the Formula 1 World Championship races.

On 1 January 2011, Fiat Industrial was formed, incorporating CNH, Iveco and FPT Industrial. In September of the same year, the Fiat Industrial Village was inaugurated in Turin, a multipurpose centre belonging to Fiat Industrial and created for the sales, assistance and product presentation for the Iveco, New Holland and FPT Industrial brands.

On 15 January 2012, Iveco won the 33rd edition of the Dakar rally with the Petronas De Rooy team and the Dutch driver Gerard De Rooy, behind the wheel of an Iveco Powerstar. De Rooy was followed by drivers Stacey and Biasion behind the wheel of two Iveco Trakker Evolution 2 vehicles, equipped with an FPT Industrial C13 engine with over 900 hp

ivecotrucks10
ivecotrucks15
ivecotrucks13
ivecotrucks19
ivecotrucks30
ivecotrucks32
ivecotrucks35
ivecotrucks31
trucksivecoawd9
trucksivecoawd14
trucksivecoawd12
trucksivecoawd25

Iveco trucks

Iveco is the brand under which the light, medium and heavy vehicles are sold. The range of light vehicles is made up of the New Daily in its versions from 2.8 T to 7.0 T and with 4x4 drive. The range of medium vehicles includes the Eurocargo, available from 7 T to 19T and with 4x2 or 4x4 drive.Stralis and Trakker, from 19 T to 72 T, make up the heavy vehicle range in two, three, or four-axled versions with all-wheel drive or two-wheel drive.

Iveco platforms

Light to Medium

  • S-series (1978), "Daily", also sold as a Fiat and as the OM Grinta. TurboDaily from 1986.

  • Z-series (1976), "Zeta". Also sold as a Fiat, OM, Magirus-Deutz, and as a Saurer-OM. TurboZeta from 1987.

Medium

  • Iveco-Magirus MK (1975) – Iveco-badged versions of Magirus' Club of Four cab were sold in Germany and some other markets.

  • Ford Cargo, sold as an Iveco-Ford in the UK from 1986 until 1991.

  • EuroCargo (1991), replaced the Zeta. Full model change in 2003, now with Bertone design.

Heavy

  • P/T/TA (1970), bonneted Magirus-Deutz off-road truck, with Iveco badging from the early 1980s. Built until 2003, mainly for non-European markets for the last decade.

  • N-series (1976), also NC and NVN. Also known as the "Turbo" or "T"-series and originally sold as a Fiat. Facelifted in 1981.

  • TurboStar/TurboTech (1984), similar to the N-series. TurboStar is the more luxurious model intended for long distance operations

  • EuroStar/Tech/Trakker (1993). Direct successors to the TurboStar/TurboTech, with the EuroTrakker being intended for offroad or construction work.

  • PowerStar (1999), a bonneted truck built and sold in Australia, using the TurboStar cabin and continuing International Australia's earlier conventional line

  • Stralis (2002), replaces the heavy "Euro" series. Facelifted in 2007 and again in 2012.

  • Trakker (2004), replaces the offroad/construction EuroTrakker and uses the same cabin as the Stralis

Iveco Bus

Irisbus was a brand specialising in passenger transport vehicles spanning from minibuses to buses for city and intercity transportation and tour buses. On 24 May 2013 the brand was relaunched as Iveco Bus.

Euro VI engines with SCR technology

Iveco engines from the Cursor and Tector ranges observe the upcoming Euro VI standards by adopting High Efficiency SCR (HI-eSCR) technology. This technology optimises the processes of exhaust combustion and after-treatment, reducing consumption and enabling achievement of greater efficiency in the conversion of NOx emission

Electric drive

Iveco developed and built the first Daily with electric propulsion in 1986; later the range was broadened to include trucks and city buses. Iveco introduced the New Daily with electric propulsion and zero exhaust emissions in which a battery system powers an electric three-phase asynchronous engine – through the aid of an inverter – in charge of moving the vehicle directly and recovering energy during braking. The vehicle runs on two to four batteries made with Na/NiCl2 (Sodium-nickel chlorine) technology at a nominal voltage of 278 Volt. The maximum velocity is electronically limited to 70 km/h and the vehicle does from 90 to 130 km on a fully charged battery, depending on the number of batteries and the missions.

Diesel-electric parallel hybrid traction

The parallel hybrid solution incorporates both a Diesel engine and an electric engine that can be used individually or simultaneously, which makes for greater operating flexibility and allows the vehicle to work under both urban and non-urban conditions. In 2010 Iveco introduced this technology on the Eurocargo Ibrido, a commercial vehicle for the European market with electri-diesel parallel propulsion for distributing and collecting goods in city centres. The payload capacity decreases by 200 kg in comparison to diesel-engine models, but it is possible to save up to 30% on the urban cycle. The Eurocargo hybrid range is made up of two versions:

  1. the 7.5-ton version uses a Tector Diesel FPT Industrial engine with 16 valves and 4 Euro V cylinders, with a maximum power of 160 hp (118 kW); this is paired with a drive system made of an electric motor-generator with 60 hp (44 kW), a 6-speed automated gearbox and a lithium ion battery pack (Li-Ion) of rated capacity 1.8 kWh.

  2. The 12-ton version uses the FPT Industrial Tector engine with 16 valves and 4 EEV cylinders with a maximum power of 180 hp (132 kW), paired with an electric motor-generator with 60 hp (44 kW), a 6-speed automated gear box and a lithium ion battery pack (Li-Ion) of rated capacity 1.8 kWh.

Diesel-electric hybrid

Iveco has been active in this sector since 1990 with 6, 7, 4 and 12 metre buses for urban transportation. The series hybrid technology features a diesel engine – smaller than that of a traditional vehicle – that acts as a battery charger.

CNG – Compressed Natural Gas

Iveco's range of light, medium and heavy vehicles and buses can run on methane. Methane makes it possible to save on consumption by 38% per kg transported as compared to that consumed by diesel engines for the same payload and distance travelled. In addition, compared to Euro VI diesel engines, methane engines reduce NOx emissions by approximately 60% and particulates emissions by approximately 70%.

LNG – liquefied natural gas

In April 2012 Iveco presented its first vehicle with this technology, the Stralis LNG. As opposed to vehicles with CNG technology, LNG technology takes the vehicle farther on a full tank (up to 750 km) and reduces the vehicle's tare thus increasing the load. The main difference between the two technologies lies in the type of natural gas storage employed, which in this case is kept in a liquid state at −161 °C in cryogenic tanks; it is then heated in a heat exchanger so that once it reaches the engine it is a gas. Also, the noise emitted decreases by 3 to 6 decibels over an analogous diesel engine vehicle.

Iveco Trakker Bifuel – diesel-ethanol prototype

Iveco created the first prototype of a bifuel, diesel and ethanol-run vehicle. The technology was developed by Iveco together with FPT Industrial and Bosch. The prototype uses a Trakker truck with Common Rail Cursor 9 engine with 360 HP that may be powered by a 40–60% ethanol-diesel blend. The prototype was tested by Raízen, a joint venture between the cane sugar producer Cosan and Shell. In 2011, this prototype earned Iveco the "Prêmio Top Etanol" – for the alternative fuel technololagy.

​

​


CURSOR ENGINES

CURSOR ENGINES - Gross & Net continuous horsepower versus rpm

CURSOR six cylinder diesel engines are offered in three sizes, and each industrial model is available in three different power ratings.  EPA Tier II certified versions of the 7.8 liter CURSOR 8 are available now.  EPA certified versions of the 10.3 liter  CURSOR 10 and 12.9 liter CURSOR 13 are scheduled to be available in December 2004. CURSOR engines use stabilized monolithic cast iron block and sub-block assemblies with wet cylinder liners, cast iron cylinder heads, roller rocker arms, a single overhead camshaft with seven supports, and feature four valves per cylinder, variable geometry turbochargers, and EUI pumping injectors with total electronic control. This gradual, progressive "electronic unit injection" control system -- which features Iveco's CAN Bus interface -- avoids typical "diesel knock" and reduces engine wear and noise.
VECTOR ENGINES - Coming to North America in 2005
The very large VECTOR V-type six, eight, twelve, and sixteen cylinder engines, with displacements of 15, 20, 30, and 40 liters, and industrial power ratings from about 700 to over 2000 HP will be available in North America in early 2005.  The V12 will be first, followed closely by the V8, then the V16, and finally, the V6. The VECTOR engine family is very robust, and is designed for a working life in excess of 25,000 hours.  The VECTOR engines feature stabilized cast iron monolithic blocks, wet cylinder liners, roller tappets and rocker arms, and singular cast iron cylinder heads with four valves per cylinder.  All models use common rail fuel injection with total electronic control via Iveco's CAN Bus interface.  English data sheets for the industrial VECTOR engines are not yet available, but a brief technical summary of essential VECTOR engine family characteristics can be downloaded

Free Access to PDF Ebooks Iveco Truck Service Manual. PDF Ebook Library ... Iveco Truck Service Manual from our library is free resource for public

[PDF]IVECO TRUCK SERVICE MANUAL

bonneted truck, the. IVECO Powerstar is the truck for you. .... life of the truck, so it reduces servicing, cuts running and ... manual transmission

[PDF]Powerstar Series Brochure - Adelaide IVECO

[PDF]Iveco Stralis FC fp ad.indd - Export & Freight

[PDF]Engine F1A





Heating and air-conditioning systems

A prototype of a heat pump system for electric and hybrid vehicles was installed on the Iveco Daily vehicle. The system cools or heats the passenger compartment by transferring low temperature heat generated by the drive systems. At the same time, the control strategies minimise the energy demand in order to achieve a low impact on consumption.

8000 series IVECO aifo ENGINES - Still available

For almost thirty years, Iveco industrial and marine engine and power generation products have been custom fit and manufactured by a separate entity known as Iveco aifo. Today, these activities are co-ordinated within the PowerTrain Division of Iveco SpA using the "umbrella" of the new Iveco Motors "brand."   Although it is certain that the new engine families described above represent the future, to insure ongoing product support and continuity, many of the 8000 series engine models developed and refined over three decades by Fiat Iveco aifo remain available from Iveco Motors.  The 8000 series range of engine models is extensive, and includes engines from the smallest 2.9 liter 8031 three cylinder family to the much larger 25.8 liter V12 enginesin the 8291 family.

Continuing applications for the 8000 series include new stationary and export installations where where current emission certifications are not required, large kW gaseous generator set applications, and as service replacements for the tens of thousands of existing Iveco aifo engines that remain in service worldwide.

The small photo at left shows a three cylinder, 2.9 liter 8031 industrial engine (this photo is linked to a larger image).

It may be a while before we have all of the 8000 series engine data summarized here on our web site.  In the meantime, information on most of these engines is available on the IVECO MOTORS website.

This includes the 8031, 8035, 8040, 8041, 8045, 8065, 8060, 8061, 8210, 8281, 8291, and 8460 engine families and their many variations.

If you have questions, please call us.

        (f) Iveco Marine engines:   Iveco Motors offers over 26 different marine engines with power ratings from 20 to 1200 hp.  Current marine engine offerings are are summarized on our separate Iveco Marine engine page.

​

NEF ENGINES - Gross & Net Continuous HP versus rpm.

With one exception (see note 1), the four and six cylinder NEF engines noted in the table below are EPA Tier II/Euro 3/CE97/68 Phase 2 certified (and EPA Tier III compliant), and are generally stocked and available in North America. An EPA Tier II  three cylinder 3.36 liter NEF engine not shown here will be available in 2005.  The robust NEF engine family features stabilized cast iron blocks and monolithic cast iron cylinder heads; structural blocks are optionally available.  Many PTO, fan, and electrical options are available for special applications.  The engine gear train is at the rear of the block.  This minimizes noise and vibration; NEF engines are among the quietest in their class.  Both mechanically governed and common rail fuel injected NEF engines with total electronic control are available.As the above photo illustrates, IVECO MOTORS offers industrial diesel engines in four new families:  the 2.3 and 3.0 liter SOFIM HPI engines, the NEF engines in I-3, I-4 & I-6 cylinder configurations with gross continuous industrial power ratings from 80 to 227 HP, the CURSOR I-6 engine family with displacements of 7.8, 10.3, & 12.9 liters and industrial power ratings from 236 to over 530 HP, and the large VECTOR V-type six, eight, twelve, and sixteen cylinder engines, with displacements of 15, 20, 30, and 40 liters, and industrial power ratings from about 700 to over  2000 HP.  In addition, many models of the older 8000 series Fiat Iveco aifo diesel engines remain available for stationary and export applications where current emission certifications are not required.
​
​
